Product finder

Find the right fifth wheel for your needs...

Material
Cast Pressed steel
Usage
Standard duty

2" on-road

Fit for...

Flexible haulage volume carriers using two and three-axle tractors.
Medium duty

2" on-road & limited off-road

Fit for...

Long-distance haulage with silo, tank and volume carriers using both two and three-axle tractors.
Heavy duty

2" on & off-road

Fit for...

HGV traffic and off-road terrain.

150SP²
Standard duty
2" on-road

Pressed

Fit for...

Flexible haulage volume carriers using two and three-axle tractors.

Reducing kingpin wear

The 150SP2 does not require a wear ring.

E11 55R–01
Approval No.		 Height
mm (DIN 6)		 Weight
kg		 Imposed (U)
T		 D-Value
kN
E11 55R–01 7166 138mm 115kg 20T 152kN
E11 55R–01 7166 148mm 113kg 20T 152kN
E11 55R–01 7166 161mm 115kg 20T 152kN
E11 55R–01 7166 185mm 117kg 20T 152kN
E11 55R–01 7166 210mm 122kg 20T 152kN
E11 55R–01 7166 230mm 130kg 20T 152kN
E11 55R–01 7166 257mm 133kg 20T 152kN
Further information

Click on the 150SP² specific parts to view and purchase

150SP² – Specific parts & repair kits

3000
Medium duty
2" on-road &
limited off-road

Cast

Fit for...

Long-distance haulage with silo, tank and volume carriers using both two and three-axle tractors.

E11 55R–01
Approval No.		 Height
mm (DIN 6)		 Weight
kg		 Imposed (U)
T		 D-Value
kN
E11 55R–01 4932 138mm 122kg 20T 150kN
E11 55R–01 4902 148mm 120kg 20T 150kN
E11 55R–01 4903 161mm 122kg 20T 150kN
E11 55R–01 4904 185mm 124kg 20T 150kN
E11 55R–01 4905 210mm 129kg 20T 150kN
E11 55R–01 4906 230mm 137kg 20T 150kN
E11 55R–01 4907 257mm 140kg 20T 150kN
Further information

Click on the 3000 specific parts to view and purchase

3000 – Specific parts & repair kits

3000lm
Low maintenance
Medium duty
2" on-road &
limited off-road

Cast

Fit for...

Long-distance haulage with silo, tank and volume carriers using both two and three-axle tractors.

E11 55R–01
Approval No.		 Height
mm (DIN 6)		 Weight
kg		 Imposed (U)
T		 D-Value
kN
E11 55R–01 5557 138mm 122kg 20T 150kN
E11 55R–01 5557 148mm 120kg 20T 150kN
E11 55R–01 5557 161mm 122kg 20T 150kN
E11 55R–01 5557 185mm 124kg 20T 150kN
E11 55R–01 5557 210mm 129kg 20T 150kN
E11 55R–01 5557 230mm 137kg 20T 150kN
E11 55R–01 5557 257mm 140kg 20T 150kN
Further information

Click on the 3000lm specific parts to view and purchase

3000lm – Specific parts & repair kits

170ci
Heavy duty
2" on & off-road

Cast

Fit for...

HGV traffic and off-road terrain.

E11 55R–01
Approval No.		 Height
mm (DIN 6)		 Weight
kg		 Imposed (U)
T		 D-Value
kN
E32 55R02/00 0104 00 148mm 140kg 25T 170kN
E32 55R02/00 0104 00 161mm 142kg 25T 170kN
E32 55R02/00 0104 00 185mm 144kg 25T 170kN
E32 55R02/00 0104 00 210mm 149kg 25T 170kN
E32 55R02/00 0104 00 230mm 157kg 25T 170kN
E32 55R02/00 0104 00 257mm 160kg 25T 170kN
Further information

Click on the 170ci specific parts to view and purchase

170ci – Specific parts & repair kits

3000ffh
Dual height
Standard duty
2" on-road

Cast

Fit for...

Flexible haulage volume carriers using two and three-axle tractors.

E11 55R–01
Approval No.		 Model
 		 Height
mm (DIN 6)		 Length
mm		 X1/X2
mm		 Imposed (U)
T		 D-Value
kN
E32 55R01/07 0047 00 FFH 167mm – 261/835 18T 130kN
E32 55R01/07 0047 00 FFH1 267mm 13mm 274/823 18T 130kN
E32 55R01/07 0047 00 FFH2 317mm 24mm 285/812 18T 130kN
E32 55R01/07 0047 00 FFH3 367mm 28mm 299/797 18T 130kN
Further information

Click on the 3000ffh specific parts to view and purchase

3000ffh – Specific parts & repair kits

260hd
Heavy duty
3.5" on-road & off-road

Cast

Fit for...

HGV traffic and off-road terrain.

E11 55R–01
Approval No.		 Height
mm (DIN 6)		 Weight
kg		 Imposed (U)
T		 D-Value
kN
Pending... 190mm 216kg 36T 260kN
Further information

Please select another option
